DESCRIPTION:
TOTAL
SEAL (High Solids) ® is a two-part epoxy coating that
has been specifically designed for use on concrete
and masonry. TOTAL
SEAL (High Solids) ® was developed to be
heavy in solids to help fill and seal imperfections, and
have original TOTAL SEAL ® to provide thickness to
the coating surface. TOTAL
SEAL (High Solids) ® was designed
to meet even the strictest V.O.C. level requirements
in the United States. This coating would be used in
lieu of TOTAL SEAL ® where the job specifications call
for higher solids.
TYPICAL USES:
* As a single product system for warehouse flooring.
* As a single product system for interior-housed concrete swimming pools.
* As a system for concrete block walls.
* As a system to repair leaking concrete walls and flooring due to hydrostatic pressure.
* Where higher solids or lower V.O.C. levels are required.
APPLICATION METHODS:
TOTAL
SEAL HS(High Solids) ® can be applied to concrete or masonry
substrates. The coating can be applied by
spray, brush or roller. For specific instructions on
surface preparation, mixing and application, please refer to the SPI's application instructions for TOTAL
SEAL (High Solids) ®
PHYSICAL DATA:
* Solids: By volume - 77% / By weight - 61%
* Dry Time: Eight hours to touch/overcoat window is twenty-four hours or longer at 70°F. degrees
* Fully cures in fourteen days
* Lead and chromate free
* Cures by chemical reaction
* Weight: 12.25 lbs. per gallon
* Vehicle Type: Amine-epoxy
* Shelf Life: up to 3 years (unopened) under appropriate storage conditions (see MSDS)
* VOC Level: White 2.75 lbs/gal 330 grams/liter
* Tinting: Can be tinted any color with a minimum of 250 gallons
* Allows only 1.5 lbs. of vapor pressure per 1,000 square feet
* Can withstand temperatures up to 400°F. degrees (205°C. degrees)
* Mix ratio: 3.75 (base) to .75 (curing agent)
* Induction period: 30 minutes @ 70°F. degrees
FIELD TESTS have proven:
* The coating has outstanding adhesion
* The coating is resistant to most solvents and chemical splashes
* The coating is flexible, yet resistant to impact
* The coating can withstand temperatures up to 400°F. (205°C. )
TESTS AND CERTIFICATIONS:
1) USDA Approved
SAFETY PRECAUTIONS:
Do not use this product without first taking all
appropriate safety measures to prevent property
damage and injuries. These measures may include, without limitation: proper ventilation, use of
proper lamps, wearing of protective clothing and
masks, tenting, and proper separation of application
areas.
This coating is flammable. Keep away from
flame, fire, or other sources of ignition.
KEEP OUT OF REACH OF CHILDREN.
For more specific safety procedures, please refer to
the TOTAL
SEAL (High Solids) ® Material Safety Data Sheet.
SAFETY PRECAUTIONS:
Do not use this product without first taking all
appropriate safety measures to prevent property
damage and injuries. These measures may include, without limitation: proper ventilation, use of
proper lamps, wearing of protective clothing and
masks, tenting, and proper separation of application
areas.
This coating is flammable. Keep away from
flame, fire, or other sources of ignition.
KEEP OUT OF REACH OF CHILDREN.
For more specific safety procedures, please refer to
the TOTAL
SEAL (High Solids) ® Material Safety Data Sheet.
MINIMUM SPREAD RATES:
* Film Thickness: Concrete and Masonry (three
coats) 6 mils wet/3.66 mils dry per coat
NOTE: The first coat should be mixed 50%/50% TOTAL
SEAL (High Solids) ® and MEK. The second and third
coat would be applied at full strength
